POF Shrink Film
The shrink material is placed over the products to be protected or consolidate and then heat is applied. This process causes the shrinkable material to contract providing a snug fit over irregular and uniform products, providing protection from dust and consolidating the products.
SK–01
COMMON STANDARD POF SHRINK FILM
Our most popular film series is SK–01. It is more economical and quality promised which is widely used in global market, not only in Southeast Asian Countries but also in European and American countries etc. We produce maximum 800 tons monthly for SK–01 POF shrink films.
Apply to:
- Manual wrapping machine
- Semi–automatic wrapping machine
- Automatic wrapping machine
PHYSICAL PROPERTY
Thickness (Micron): 12.5, 15, 19, 25, 30
TENSILE PROPERTY (MD/TD)
| Property | Unit | Test Method | Representative Value | ||||
|---|---|---|---|---|---|---|---|
| Tensile Strength | N/mm² | ASTM/882 | 110/110 | 110/110 | 110/110 | 100/100 | 100/100 |
| Elongation at Break | % | ASTM/882 | 90/90 | 90/90 | 95/95 | 100/100 | 110/110 |
| Seal Strength | 180℃N/15mm | 12.6 | 13.8 | 19.1 | 24.2 | 27.6 | |
| Tear | g | ASTM D1922 | 10.1 | 13.5 | 17.1 | 23.2 | 28.7 |
| COF | Adim | ASTM D1894 | 0.22 | 0.20 | 0.19 | 0.21 | 0.19 |
| Free Shrink at 120℃ | % | ASTM D2732 | 55/60 | 52/58 | 51/57 | 50/57 | 50/55 |
DIMENSION SPECIFICATION
| Width | 150–2000 mm | |||||
|---|---|---|---|---|---|---|
| S/(Single layer) | 3200m | 2665m | 2135m | 1600m | 1335m | |
| C/F (center fold) | 1600m | 1332m | 1067m | 800m | 667m | |
Values listed above are average test values to be used for reference information purposes, subject to possible variations. Products are to be stored in dry conditions below 35℃.
